Outdoor Fiber Optic Equipment for Cable Production Line
Outdoor Fiber Optic Equipment for Cable Production Line
Supply Ability:
0 per 0
Port:
Your Email:
Quantity:
  • Product Detils
  • Company Profile
Quick Details
Place of Origin:
China (Mainland)
Brand Name:
Model Number:
Product Description

Basic Info

  • Model NO.: HR-SZ-800

  • Automatic Production Line: Comprehensive

  • Automation: Automation

  • Rhythm: Flow Production Line

  • Motor Brand: Siemens

  • Bearing: SKF or NSK

  • Trademark: HONGRONG

  • Specification: Customized

  • HS Code: 8479400000

  • Transmission Type: Flexible

  • Certification: ISO, CE

  • Flexible Production: Intelligent Manufacturing

  • Production Scope: Product Line

  • Inverter: Siemens

  • Color: Customized

  • Transport Package: Wooden Case

  • Origin: Dongguan, Guangdong

Product Description

Outdoor Optic fiber cable machine

1. Application: apply to extruding the inner and outer sheath of outdoor cable, extruding material can be LDPE, MDPE, HDPE, PA12 and HRRF.

2. Specifications

2.1 Cable core dia.                                         5-25mm

2.2 Cable-sheathed outer dia.                        6-30mm

2.3 Line speed:                                              10-80m/min

                                                                       (80m/min,OD≤9mm)
2.4 Line structure speed                               100m/min

2.5 Length of the line                                   <70m

2.6 The line center height                             1000mm

2.7 Screw pole type                                       BM

2.8 Operation direction                                  right to left (or appointed by user)

2.9 Line colorappointed by user

2.10 Pay-off reel size                                     PN800~PN2000

2.11 Take-up reel size                                   PN800~PN2000

2.12 Extruding output                                    max.250kg/h (PE)

2.13 Metering accuracy                                 0.3%

2.14 Installed power                                      230kVA

2.15 Total weight                                           20T

Outdoor Fiber Optic Equipment for Cable Production Line

Outdoor Fiber Optic Equipment for Cable Production LineOutdoor Fiber Optic Equipment for Cable Production LineOutdoor Fiber Optic Equipment for Cable Production Line


1. We produce indoor and outdoor optical cable equipment:

A. Indoor fiber cable equipment:

a). HR-35 tight buffer production line: apply to produce tight buffer with PVC or LSZH.

b). HR-50/70 (stranded) premise cable production line:  apply to produce premise cable, such as simplex, duplex or no more than 12 cores, also can strand and sheath tight buffer to make multi-core distribution cable. Extruding material can be PVC, LSZH etc.

c). HR-50 FTTH cable production line: apply to produce FTTH drop cable, extruding material can be PVC, PE, LSZH etc.

d). SZ premise cable stranding line: apply to multi-core SZ stranding of premise cable.

e). Rewinding machine for tight buffer and premise cable: apply to rewind tight buffer or premise cable.

B. Outdoor fiber optic cable equipment:

a) Coloring and rewinding machine: apply to color and rewind optic fiber.

b). HR-50 secondary coating production line: apply to produce loose tube with PBT or PE.

c). SZ stranding line: apply for sz stranding of loose tube.

d). HR-90/120 sheathing production line: apply to produce different kinds of outdoor optical cable with material PE.

e) Rewinding machine for outdoor fiber cable: apply to rewind outdoor fiber cable from one bobbin to another.

randing machine for making wire and cable


We begun to produce cantilever single twisting machine since 2000. Since then we have been made many sets of this kind of single twisting machines for our customers home and abroad. We have been dedicated into making cable machine since 1983. I am pretty sure that we can offer you the best solution for the cable production line with the most competitive price.

3) Q&A
1. Are you the manufacturer or trading company?
We are the 100% manufactuer with 3 big workshops covering over 100, 000.00 square meter. Warmly welcome you to visit our factory and conduct our work.
2. What's your factory's advantage over other manufacturers in the same industry?
- High output capacity will guarantee your high-efficient production
- We are very good at engineering. In order to make our machine have a very excellent performance, we are rigorously attaching importance to each detail in the course of manufacturing in a bid to improve our machines continuously.
- We only mount electrical components under famous brands like Siemens, Yaskawa, Scheinder and Omron on our machines to guarantee the quality of our machines.
- Our engineers and workers can work abroad, if you need us to assist you installing and testing the machines or training your staff how to operate and maintain our machines, we can send our team to your factory when our machines arrive at your factory.
- Guarantee period: We can guarantee one year for all our machines.
- After-sales service: We promise to provide permanent technical support and after-sales service with our customers.
3. Why do we trust your company?
We are gold supplier for many years and have agent in Europe. Up to now, we have exported our machines to many countries.

Our factory and workshop
Outdoor Fiber Optic Equipment for Cable Production Line
Outdoor Fiber Optic Equipment for Cable Production Line


Please use the factory-direct-buy message to contact us. We will reply in 24 hours.
