Oil tanker, fuel tanker, Fuel Tank Trailer, Oil Tanker trailer
Oil tanker, fuel tanker, Fuel Tank Trailer, Oil Tanker trailer
Supply Ability:
300 Piece/Pieces per 0
Port:
qingdao
Email:
Quantity:
Piece
  • Product Detils
  • Company Profile
Quick Details
Place of Origin:
China (Mainland)
Brand Name:
fawtruck
Model Number:
HTC9411GG
Packaging & Delivery
Product Description

Oil tanker,fuel tanker, Fuel Tank Trailer, Oil Tanker trailer

We are one truck refitting enterprise approved by National Ministry Of Industry and Information Of China. We can supply from 2 tons to 70 ton trucks and various semi trailers. And we can provide all of the brands truck chassis made in China. HOWO, FAW,DONGFENG,FOTON,SHACMAN,BEIBEN,C&C, and so on. The followed specifications are for HOWO A7. You can contact us directly and tell us you wanted brand and specifications, we'll recommend the suitable model to you.

40000-60000L Fuel Tank Trailer (HTC9411GG)Oil-tanker-fuel-tanker-Fuel-Tank-Trailer-Oil-Tanker-trailer - 副本.jpg

Fuel Tank Trailer, Oil Tank Trailer(40-100cbm)
Dimension:
Length: 12, 800 mm
Width: 2, 485 mm (including mud guard)
Height: 3, 600mm
King Pin Location: 1, 000 mm from the front face of the front bolster
Axle spacer: 7, 400mm + 1, 400mm
Fifth Wheel Height: 1, 280mm with the chassis level.
Landing Gear location: 2420mm behind the king pin location

Weight:
Tare weight(Tolerance 0~-4%): Approximate 10, 800KG
Pay Load: 41, 700KG
G. V. W. R: 52, 500KG
King Pin Distribution: 16, 750KG
Axle Group Distribution: 32, 950KG

Tank:
Volume: 35000LT + 5%, Vapor Volume for semi trailer
Three compartments: 2350L/20000L/15000L
Plus outside fitted fuel tank 2350L capacity situated inside the main tank at the front of the tank with proper inlet (16" diameter manhole) and outlet (a ball-type discharge valve and a thread coupling, made in China, lies to roadside. ).
Tank material: Steel plate Q345A, the thickness of the shell is 5mm approx.
Dish ends and bulkhead: Dished and flanged, steel plate Q345A, thickness are 5mm approx, and baffles are 4 mm approx, steel plate Q235A.
Shape of tank: Ellipse, double "D"
Plate dealing: Outer surface paint. Color according to the customer's requirement. Internal antistatic coating.
Test pressure designed: 36kpa.

Tank Accessories and fitting:
16" diameter manhole pre compartment.
Each compartment has a 4" foot valve, pneumatic operation.
Each compartment has a 3" steel pipe line.
At the middle of the tank, each compartment with a 3" ball-type discharge valve and a male coupling (To be determined), lies to roadside.
At the rear of the tank, a detachable ladder is provided.
A chequered plate walkway is installed on top of the tank made of antiskid plate.
Each compartment has a measurement ruler. According to the regulation of Chinese metrology department, the measurement ruler for fuel tanker semitrailer should be calibrated above 70% of the tank volume and below 70% the ruler doesn't need be calibrated. From 70% to 85% of the tank volume, we can calibrated the ruler and it can reach 300 liter/step. And above 85% of the tank volume, we can make the precision of the measurement ruler reach 100 liter/step. (calibrated by CIMC)
Expansion valve: Non.
Pump is option

Oil-tanker-fuel-tanker-Fuel-Tank-Trailer-Oil-Tanker-trailer2 - 副本.jpg
