Model Designation
| F3 | -25VQT | -A | -B | -21 | -A | -2 | -297 |
Series | Thru-drive connection | Mounting flange | Flow code | connections | Thr-drive coupling | Shaft type | |
F3:Fluoro rubber seals No standar seals | 25VQT | A B BP C | B 101-2 | 12,14,17,21 | 4-bolt flange | 2-SAE splined couping. include with pump |
202-Straignht key |
| 35VQT | C 127-2 | 25,30,35,38 | |||||
| 45VQT | C 127-2 | 42,50,60 |
Outlet Position(Viewed from cover enf of pump)
| -A | -A | -20 | -R |
Outlet positions |
| Design number | Rotation |
| A-A adapter Rotated 45° CW with respect to pump mtg.flg. A-B adapter In line with pump mtg.flg. B-A adapter Rotated 45° CCW with respect to pump mtg.flg. B-B adapter Rotated 90° with respect to pump mtg.flg. | 21-29 | L-Left hand (counter-clockwise) R-Right hand (clockwise) |
