Quick Details
Place of Origin:
China (Mainland)
Product Description
Basic Info
- Model NO.: SZLH420
- Processing Object: Mixed Feed
- Screen Mesh: With Screen Mesh
- Pellet Mill Type: Ring Die Pelleter
- Expanding Method: Dry Expansion
- Applicable Materials Shape: Powder
- Main Motor: 110kw
- Conditioner Power: 7.5kw
- Rollers Qty: 2 PCS
- Size: 3500*1300*2800 mm
- Roller Od: 206mm
- Specification: CE
- HS Code: 8474802000
- Type: Pellet Mill
- Processing Technics: Crushing-before-Mixing
- Grinding Equipment Type: Feed Hammer Mill
- Bulking Machine Type: Sigle Screw Bulking Machine
- Condition: New
- Name: Animal Feed Pellet Mill
- Feeder Power: 1.5kw
- Diameter of Mould: 420mm
- Capacity: 8-10t/H for Animal Feed
- Ring Die Speed: 287rpm
- Trademark: Azeus
- Origin: China
Product Description
1. Detail Specification: (1)This series pellet mill suitable for making all kinds of animal feedstuff. Which capacity 1000-200000 kg for feed factory .(2)The machines can be match different size of ring die hole size , such as φ1.0,φ1.2,φ1.5,φ2.0,φ2.5,φ3.0,φ3.5,φ4.0,φ4.5,φ5.0,φ6.0,φ8.0 , always for making shrimp, fish feed to use for φ1.0--3.5 ring die ; chicken feed for φ3.0; Swine feed for φ3.0--4.5; Cattle, horse for φ6.0--8.0).(3)The machine adopt imported SKF or NSK bearings, the motor brand is Siemens or china famous Wannan brand .Driven by gear .more strong than by belt, and the capacity 10% higher than by belt .(4)The machine also matched the safty equipment , once overload , the safty pin will crack, to protecting the machine lifetime 2. Quotation Details :(1)Payment: 40% payment should be prepaid by telegraph transfer, the balanced 60% should be paid within 5(five) days after got the copy of B/L (2)Delivery Time: 25- 30 days after receive the advance payment (3)Price based on FOB Shanghai port,China Per Set(4)Packing: Standard export packing by Fumigation-free wooden cases(5)MOQ:1set (6)Validity of Quotation: 2 months(7) Warranty Period: 18 months except the spare parts 3.Ring Die Feed Pellet Mill Technical Parameter:| Model | SZLH320 | SZLH350 | SZLH400 | SZLH420 | SZLH508 |
| Capacity | 2-5T/H | 1.5-8T/H | 2-10T/H | 3-12T/H | 4-20T/H |
| Main Motor Power | 37KW | 55KW | 75/90KW | 110KW | 132/160KW |
| Screw Feeder Power | 0.55KW | 0.75KW | 0.75KW | 1.5KW | 1.5KW |
| Conditioner Power | 2.2KW | 2.2KW | 2.2KW | 5.5KW | 7.5KW |
| Ring die inner diameter | 320mm | 350mm | 400mm | 420mm | 508mm |
| Ring die rotational speed | 305PRM | 336PRM | 307PRM | 287PRM | 287PRM |
| Roller outer diameter | 140mm | 165mm | 190mm | 206mm | / |
| Dimension | 2300*1000*2100 mm | 3200*1100*1700 mm | 3200*1300*1900 mm | 3500*1300*2800 mm | 3500*1500*2900
mm |
Pellets shaping rate: ≥95%
Pellets stability in water: ≥20Min
Noise: ≤86dB(A) ≤90dB(A)
Roller working temperature: ≤85ºCSteam working pressure: 0.1-0.4Mpa
Steam temperature: 130-150ºCTo Know more, please contact winni Cell: 0086-13721419972
