Engine Large Power Tractor,90hp 4wd Farm Tractor Agricultural Implements
Product Description
1.Lawn large garden tractors are powered with the famous YTO/YUCHAI brand engine , Vertical Water Cool 4-stroke and 4 cylinder. It offers high performance, low fuel consumption and vibration noise.
2, Double action clutch of cheap large power garden tractors is installed for independent operation.
3,Full hydraulic steering system of multifunction large tractors adopt smaller turning radius, being flexible and reliable.
4,Combination 4×(2+1)×2 gear box of agricultural tractors has 16 forward gears and 8 backward gears for easy operation and higher efficiency.
Specification
| Model | QLN-900/904 | ||
| Dimensions | Length×Width×Height(mm) | 4280×2085×2925 | |
| Wheel Tread(mm) | Front Wheel(mm) | 1610—1820(4WD) 1520—1820(2WD) | |
| Rear Wheel(mm) | 1620—2020 | ||
| Min.Ground Clearance(mm) | 370—450 | ||
| Dry Mass | With Cab(kg) | 3635(2WD) 3785(4WD) | |
| Without Cab(kg) | 3420(2WD) 3570(4WD) | ||
| Engine | Trade Mark or Brand | YTO/YUCHAI | |
| Engine Model | Vertical Water Cooled 4-stroke | ||
| Directly Injection | |||
| Number of Cylinder | 4 | ||
| Cooling System Type | Water Cooled | ||
| Rated Power(kw) | 66.2KW | ||
| Max. Torsion(N.M) | 360 | ||
| Rated Speed(r/min) | 2300 or 2400 | ||
| Fuel Tank | Volume(L) | 150 | |
| Transmission System | Clutch | Single,Dry,Dual Stage Type | |
| Gear Box | F16+R8/F16+R8(creeper gear) | ||
| Differential | Closed 4-planetary Gears | ||
| Differential Lock | Mechanical Sliding Sleeve | ||
| Braking System | Wet Double Plate Disc Brake | ||
| Running System | Tyre Model | F/R(2WD) | 6.5—20/16.9—34 |
| F/R(4WD) | 11.2—24/16.9—34 | ||
| Steering System | Hydraulic Wheel Steering | ||
| Working Device | Hydraulic System Type | Positive lifter | |
| Linkage Type | II Rear Mount 3-point Linkage | ||
| PTO(Standard) | φ38,8teeth φ35,6teeth | ||
| PTO Speed(r/min) | 540/1000 | ||
| Drawbar Type | Fixed Drawbar/Swing Drawbar | ||
Packaging & Delivery
Engine Large Power Tractor,90hp 4wd Farm Tractor Agricultural Implements
Standard packing or As per customer's request
Our Company
Feicheng Haochuang Group Work Win Co., Ltd. is a leading manufacturer and provider of total integrated supply chain solutions. We offer the best agricultural machinery products for the orders.We have a multilingual team, and many big branch factories. A regional market presence-including southeast Asia, Indonesia, Russia, Spain, Chile, Brasil, Australia etc.Group Work Win strives to build a long term relationships by providing our customers with continuous and reactive support. We aim to supply better quality products and after-sales service.
FAQ
1.Are you tractor supplier or manufacturer?
We are tractor manufacturer. We can provide the complete tractor and spare parts with favorite price, because we are the source.
2.Can you supply tractor farm implements?
We can supply series farm implements, such as disc plough, harrow, loader, backhoe, trailer etc you want. But firstly, tell us your preferred horsepower tractor.
3.what are your products?
Our products contain walking tractor 10-18 hp, farm tractor 25-220 hp ,harvester and matched agricultural implements.
4.What's your payment method?
Support L/C,D/A,D/P,T/T,and other secure payment.
5.When do you ship after payment?
Within 15 to 20 working days after delivery.
