| FOB Price: | US $8,590 / Piece |
|---|---|
| Min. Order: | 1 Piece |
| Min. Order | FOB Price |
|---|---|
| 1 Piece | US $8,590/ Piece |
Basic Info
Model NO.: 4YZP-2Q
Application: Corn
Harvest method: Uprooted
Transmission: Soft Shaft
Certification: QS, SGS, ISO9001:2008
Condition: New
2: Row
Transport Package: 40′ Contaienr Can Load 2 Set
Origin: Shangdong
Type: Vertical Cut Harvester
Power Source: Diesel
Drive Type: Gear Drive
Portable Harvester Type: Backpack Type
Color: Red
Application Field: Agriculture
Trademark: SH
Specification: SGS
HS Code: 8433510090
Product Description
Structural features
1. Compact structure, good mobility, no manual to clear the way, can complete corn crop snapping, transportation, bract stripping ear, ear closed container, straw chopper or collect the whole process.
2. it pulled the chain using forced feeding technology to solve a variety of problems spacing adaptability.
3. Pull stalk rolls, snapping plate Abstract simple ear device structure, small size, light weight, low grain loss, high production efficiency.
4. Pre-peeling machines, branches dial skin, to prevent clogging
5. It is the shortest, lightest, most full-function self-propelled two-row harvester.
6. 4 wheel drive, better mobility.
7. Hydraulic steering flexible and comfortable operation
8. Middle cargo hopper, hydraulic lifting and unloading the corn
| No. | Item | Unit | Design value | |
| 1 | Model Specification | / | 4YZP-2Q | |
| 2 | Structure type | / | Self-propelled | |
| 3 | Matching engine | Model | / | 2105, 2 cylinder diesel engine |
| Rated Power | kw | 24 | ||
| Rated speed | r / min | 2200 | ||
| 4 | Dimensions (L × W × H) | mm | 4270 × 1440 × 2200 | |
| 5 | Structural weight | kg | 1900 | |
| 6 | The number of lines of work | Row | 2 | |
| 7 | Applicable spacing range | mm | 400 to 700 | |
| 8 | Working width | mm | 1600 | |
| 9 | Maximum unloading height | mm | 1660 | |
| 10 | Maximum elevator through a highly | mm | 2900 | |
| 11 | Minimum ground clearance | mm | 235 | |
| 12 | The minimum radius by | Turn left | mm | 3400 (outside) |
| Turn right | 3400 (outside) | |||
| 13 | Theory of operating speed | km / h | 2-4 | |
| 14 | Operating hours of productivity | hm 2 / h | 0.15 ~ 0.26 | |
| 15 | Fuel consumption per hour | L/H | ≤ 5.8 | |
| 17 | Snapping roll type | / | Horizontal pick roller | |
| 18 | Peeling roller type | / | Cast iron roll rubber roller | |
| 19 | Transmission Type | / | Mechanical gear | |
| 20 | Tire Size | Guide wheel | / / | 6.00 - 16 |
| Wheels | 9.50 - 24 | |||
| 21 | Type chopped straw | Blade | ||
| 22 | Corn cargo hopper | cbm | 0.4 | |
