Basic Info
Model NO.: SH1404
Usage: Farm Tractor
Drive Wheel: 4WD
Fuel: Gas / Diesel
Size: Large
Condition: New
Wheel Drive: 4WD
Operate Weight: 5460kg
Transport Package: in 40′high Container
Origin: Shangdong
Type: Wheel Tractor
Certification: ISO, CE, ISO/TS16949
Emission Standard: Euro II
Service Life: 6-10 Years
Color: Green
Power: 140HP
Cab: with AC
Trademark: SH
Specification: SGS
HS Code: 8701901190
Product Description
The DF Series Heavy wheeled tractors are our new kind of heavy tractor, they are designed for drylands job, they can attach many kinds of large farm machineries.
They are widely used in China's Xinjiang, Northeast farm land deep plowing, crop planting, cultivation, fertilization and forage mechanization and transportation of materials.
More suitable for supporting a complete multi-channel processes jobs with duplex farm machinery.
In addition, supporting the corresponding device, they can complete the transformation of farmland water conservancy construction, engineering machinery and many other jobs.
| Operate weight with Cab |
| 5240kg |
| Wheel driven and Steering |
| Four wheel driven with hydraulic steering |
| Hydraulic system |
| Dual hydraulic output |
| Fuel tank capacity |
| 270L |
| PTO |
| 8 spline , 38mm outside diameter 760 / 1000 R.P.M |
| ENGINE |
| Model DZ2012 in-line , 6 cylinder , water cooled Turbocharged . |
| Rated speed : 2100 R.P.M , Gross HP 140 |
| Bore * stroke : 120* 125 mm |
| Displacement : 6.057 L |
| Oil bath type air filter |
| Differential Lock |
| Improve the pass-ability |
| Transmission |
| Dual stage clutch by independent control |
| Transmission is variable speed controlled to maintain 760/1000 PTO speed |
| Ground Speed |
| Travel speed ( 40F+40R , creeper ) |
| High creep : 3.23-50km/h |
| Low creep : 0.39-8.039 km/h |
| Brake |
| Static-pressure pedal control |
| Suspension |
| 4 x sets remote hydraulics |
| Three-point linkage on postposition |
| Dimension |
| ( L x H x G ) : 4590 x 2304 x 2922 mm |
| Wheelbase : 2647 mm |
| Wheel track ( Front / Rear ) : 1700-1900 mm 1600-1850mm |
| Minimum ground clearance : 520mm |
| Roll over protection bar / cab / seatbelt / counterweight are optional |
| Air condition / luxury s |
| Tires |
| Front / Rear : 12.5-30 / 18.4-38 |
