fiber laser cutting for steel sheet metal tube aluminium alloy
fiber laser cutting for steel sheet metal tube aluminium alloy
  • >= 90000   US $120,000.000
Supply Ability:
0 per 0
Port:
QINGDAO
Email:
Quantity:
  • Product Detils
  • Company Profile
Quick Details
Place of Origin:
China (Mainland)
Brand Name:
XT Laser Fiber Laser Cutting Machine
Model Number:
1530 fiber laser cutting machine
Packaging & Delivery
Product Description

Features and Advantages of 1530 Fiber Laser Cutting Machine For Stainless Steel And Mild Steel 1530:

  1. Compact structure, small floor area.

  2. Stability and reliability of light path system and control system.

  3. High performance and low operating cost, famous IPG fiber laser with up to more than 100 thousand hours life-cycle.

  4. Higher cutting quality and efficiency, cutting speed is up to 15 m/min with appearance and beautiful cutting edge.

  5. High precision serve motors, lead screws and guide ways with famous brands to ensure the efficiency and accuracy, greatly increasing the stability and reliability.

  6. Fiber Laser Cutting Machine XTC-F500 has faster cutting speed and higher quality cuting result compared to other cutting solutions. Fiber Metal Laser Cutting Equipment XTC-F500 Series adopts the most sophisticated America IPG laser, combining CNC Machinery designed by our company and high strength welding body, after standard heat treatment and process machining by large CNC milling machine

Fiber Laser Cutting Machines Series Model:

  1. XTC-F500 Fiber Laser Cutting Machine 3000X1500mm

  2. XTC-H150/180/200 Fiber Laser Cutting Machine 2500X1300mm

  3. XTC-Y600 Fiber Laser Cutting Machine 3000x1500/2500*1300/1200*1200mm

    (Remark: Specific model should be produced with signed contract)

Technical Parameters of 1530 Fiber Laser Cutting Machine For Stainless Steel And Mild Steel 1530:

Model

XTC-F500

XTC-F300

XTC-F1000

Working Area

3000X1500mm

3000X1500mm

4000x2000mm

Laser Type

Raycus Fiber laser generator

Laser Power

500W

Cutting Thickness

0-10mm

Cutting Speed

0-30m/min

Laser Wavelength

1064 nm

Positioning Accuracy

≤ ±0.03mm/m

Re-positioning Accuracy

≤±0.02mm/m

Max Cutting Speed

30m/min(depending on material and thickness)

Power Supply Rated Voltage

3-phase 380V/50Hz

X-axis Stroke

3000mm

3000mm

4000mm

Y-axis Stroke

1500mm

1500mm

2000mm

Z-axis Stroke

120mm

Working Table

Rack working platform

Control System

Baichu Cypcut CNC control system

Location System

Red dot indicator

Water Cooling System

Constant temperature water chiller

Machine Weight

2000-8000kg

Machine Dimension

3500x1800x1600mm

4300x2500x1600mm

5000X2900X1600mm

Remark

Automatic exchange worktable, cover(option)




XTC-F500 Fiber Laser Cutting Machine
