Product description:

The rated temperature: - 20 ° ~ 100 ° (200 ℃) can be customized

Case material: stainless steel (304)

Cable length: 6000mm (can be customized)

Probe length: 195mm

Probe length: 230mm

Tail connection thread: M24*1.5*50

Product quality: 1.5kg

Introduction to the

TS plug the switch, also known as the coal slip switch.Is a simple structure, easy to use, safe and reliable material flow, material flow detector, its volume is small, solid and corrosion-resistant.Use: chute or transfer blockage detector: conveyor belt deviation detector: dumper unloading probe: used for belt and vibration feeder to detect lack of material or no material -- imported American technology and internal components.

The working principle of

When the plug switch with vertical suspension receives contact action inside the switch when it is acted upon by external forces and deviates from the vertical position more than 15 degrees, the normally closed contact is broken (or the normally open contact is closed).When external undo occurs, the plug switch returns to the vertical position and the contact is closed (or disconnected) again.The change of contact opening and closing in the plug switch is used to judge the working condition of the equipment, and measures should be taken timely to protect the equipment.
