Dutch Techonlogy Film Multi-Span Green House with Substrate Culture
Dutch Techonlogy Film Multi-Span Green House with Substrate Culture
FOB Price: US $30 / Square Meter
Min. Order: 1,000 Square Meters
Min. Order FOB Price
1,000 Square Meters US $30/ Square Meter
Supply Ability:
0 per
Port:
Qingdao, China
Your Email:
Quantity:
  • Product Detils
  • Company Profile
Quick Details
Place of Origin:
China (Mainland)
Brand Name:
Model Number:
Product Description
Basic Info
  • Model NO.: BS-FGH-294
  • Size: Large
  • Layer: Single
  • Life Span: 20 Years
  • Material 1: Film+Hot Gal Steel Tube
  • Transport Package: Flat Pack
  • Origin: Qingdao, China(Mainland)
  • Type: Production Greenhouse
  • Cover Material: Film
  • Customized: Yes
  • Easy Installation: Yes
  • Trademark: Bluesky
  • Specification: Plastic Film, Hot Gal Steel Tubes
  • HS Code: 940600000
Product Description
Features of film greenhouse:
The multi-span plastic film greenhouse is the most economical and affordable greenhouse.

1. Simple structure and economic type
The bearing structure, fixed film systems and installation of this greenhouse is relatively simple. Its bearing structure use hot-dip galvanized light steel, the longitudinal bars connect the rod and beam, and using pressure film line to fixed the film, the tension of the line is negative pressure through the film, which is uniform force passed to the gutter, greatly optimizing the greenhouse structure stress.
And because of its simple structure, raw material and manufacturing costs are affordable. Except the  high strength woven film is higher, other kinds of antidrop film are economical. In general, the comprehensive cost of film greenhouse is lower 30% ~ 50% than the same size and specifications of the other types of greenhouse.

2. Structure is flexible, strong applicability and wide applicable scope
Film greenhouse can design based on various factors such as geographical characteristics, customer requirements into different span, height, roof shape etc.. Any climate can be used, especially in the area, where light resources is adequate. It can be used for a variety of plants, and due to some film can create light scattering environment, it is much more conducive to the growth of plants.


3. Greenhouse specifications:
SpanBayEave heightTotal Height
7m/8m/9m/10m4m2.5m-4.0m4.2m-6m
P.S.: size can be customized.

Performance index of SP-M-8 Greenhouse:

Δ Wind load: 0.50KN/m2

Δ Snow load: 0.25KN/m2

Δ Maximum drain volume: 140 mm/h

Δ Electrical parameters: 220V 50HZ PH1/380V 50HZ PH3, can be equipped with frequency converter to meet customer demand.

Δ Steel structure: hot-dip galvanizing carbon steel, design working life is 10 years.

You can increase auxiliary facilities in your greenhouse as you needed, just cost some more money.

We provide after-sales installation and debugging, Our engineers could serve at site. But please note this cost is not included in the quotation.

For more information, please contact us:
Qingdao Bluesky Greenhouse Co.,Ltd
Add: Qingdao, Shandong, China.
www.lantianwenshi.com
Mobile: +86 185 6064 9979





Please use the factory-direct-buy message to contact us. We will reply in 24 hours.
